AXEON LC-750 RO System 110V: Reverse Osmosis System Optimized for Light Commercial Applications

Features: White Powder Coated Steel Bracket AXEON 2.5″ x 20″ 5-Micron Sediment Pre-Filter AXEON 2.5″ x 20″ 10-Micron Carbon Block Pre-Filter (on LC – 750) Pentair® 20″ Slim Line Cartridge Housings Fluid-O-Tech™ Low Lead Brass Rotary Vane High Pressure Pump ODP High Efficiency Carbonator Motor AXEON HF5 – Series Ultra Low Energy Membrane Elements Permeate Flow Meter Concentrate Flow Meter with SS Integrated Needle Valve Concentrate Recycle Flow Meter with SS Integrated Needle Valve Feed Solenoid Valve 0-300 psi Pump Pressure Gauge 0-100 psi Post-Filter Pressure Gauge 0-100 psi Permeate Pressure Gauge John Guest® Push/Pull Fittings with Locking Safety Clips Low Pressure Switch for Pump Protection Permeate High Pressure Switch HM Digital® DM– 2 Dual TDS Meter 20″ Floor Stand Blending Valve Specifications: Model: LC-750 Capacity (gpd): 750 Design: Configuration: Single Pass Feedwater Source: TDS < 1,000 ppm Standard Recovery Rate %: Up to 75 Flow Rates: Permeate Flow (gpm): 0.52 Minimum Feed Flow (gpm): 2.22 Maximum Feed Flow (gpm): Up to 8 Connections: Feed (in): 1/2″ QC Permeate (in): 3/8″ QC Concentrate (in): 3/8″ QC Membranes: Membrane(s) Per Vessel: 1 Membrane Quantity: 1 Membrane Size: 3018 Nominal Salt Rejection %: 98 Vessels: Vessel Array: 1 Vessel Quantity: 1 Pumps: Pump Type: Rotary Vane 401 Low Lead Brass Motor HP: 1/3 RPM @ 60Hz: 1725 System Electrical: Standard Voltage Amp Draw: 110V, 1 PH, 50 / 60Hz, 6.6A Operating Limits: Maximum Feed Temperature (°F / °C):  85 / 29 Minimum Feed Temperature (°F / °C):  40 / 4 Maximum Ambient Temperature (°F / °C): 120 / 49 Minimum Ambient Temperature (°F / °C): 40 / 4 Maximum Feed Pressure (psi / bar): 70 / 4 Minimum Feed Pressure (psi / bar): 40 / 3 Maximum Operating Pressure (psi / bar): 90 / 6 Maximum Feed Silt Density Index (SDI): < 3 Maximum Turbidity (NTU): 1 Maximum Free Chlorine (ppm): 0 Maximum TDS (ppm): Up to 1,000 Maximum Hardness (gpg): 1 Maximum pH (Continuous): 11 Minimum pH (Continuous): 2 Maximum pH (Cleaning 30 Minutes): 13 Minimum pH (Cleaning 30 Minutes): 1
