AXEON LP-700: Reverse Osmosis System Optimized for Light Commercial Applications

Features: Cover with Glycerin-Filled Pressure Gauges (Post-Filter, Operational Pressure, and Permeate Pressure) DM-2 Dual TDS Monitor TE-3012-500 Membrane Element 3012 Membrane Housing 2.5″ x 20″ 5-Micron Sediment Pre-Filter 2.5″ x 20″ 10-Micron Carbon Block Pre-Filter and Post Filter 20″ Slim Line Cartridge Housings Automatic Shut-Off Valve Push/Pull Fittings with Locking Safety Clip   Specifications: Model: LP-700 AXEON Part Number: 208896 Capacity (gpd): 700 Design: Configuration: Single Pass Feedwater Source: TDS <500 ppm Standard Recovery Rate %: 38 Flow Rates: Permeate Flow (gpm): 0.49 Minimum Feed Flow (gpm): 1.33 Connections: Feed (in): 3/8″ QC Permeate (in): 3/8″ QC Concentrate (in): 3/8″ QC Membranes: Membrane(s) Per Vessel: 1 Membrane Quantity: 2 Membrane Size: 3012 Nominal Salt Rejection %: 98 Vessels: Vessel Array: 2 (Parallel) Vessel Quantity: 2 Pumps: Pump Type: N/A Motor HP: N/A System Electrical: Standard Voltage Amp Draw: N/A Operating Limits: Maximum Feed Temperature (°F / °C):  85 / 29 Minimum Feed Temperature (°F / °C):  40 / 4 Maximum Ambient Temperature (°F / °C): 120 / 49 Minimum Ambient Temperature (°F / °C): 40 / 4 Maximum Feed Pressure (psi / bar): 90 / 6 Minimum Feed Pressure (psi / bar): 70 / 5 Maximum Operating Pressure (psi / bar): 90 / 6 Maximum Feed Silt Density Index (SDI): <1 Maximum Turbidity (NTU): 1 Maximum Free Chlorine (ppm): 0 Maximum TDS (ppm): 500 Maximum Hardness (gpg): 1 Maximum pH (Continuous): 10 Minimum pH (Continuous): 4 Maximum pH (Cleaning 30 Minutes): 12 Minimum pH (Cleaning 30 Minutes): 2
