AXEON L1-200 RO System 110V: Reverse Osmosis System Optimized for Light Commercial Applications

Features: AXEON HF4 – Series Extra Low Energy Membrane Elements AXEON FRP– Series 300E Fiberglass Membrane Housing AXEON 5-Micron Sediment Pre-Filter AXEON 10-Micron Carbon Block Pre-Filter and Post-Filter Pentair® 10″ Slim Line Cartridge Housings AXEON 0-300 psi Glycerin-Filled Pump Pressure Gauge AXEON 0-100 psi Glycerin-Filled Pre-Filter Pressure Gauge AXEON 0-100 psi Glycerin-Filled Permeate Pressure Gauge Aquatec® Tank High Pressure Switch Composite Feed Solenoid Valve Aquatec Auto Flush Timer Valve Aquatec High Flow Booster Pump John Guest® Push/Pull Fittings with Locking Safety Clips     Specifications: Model: L1-200 AXEON Part Number: 207315 Capacity (gpd): 200 Design: Configuration: Single Pass Feedwater Source: TDS <1,000 ppm Standard Recovery Rate %: 40 Rejection and Flow Rates: Permeate Flow (gpm): 0.14 Minimum Feed Flow (gpm): 0.35 Minimum Concentrate Flow (gpm): 0.21 Nominal Salt Rejection %: 98.5 Connections: Feed (in): 3/8″ QC Permeate (in): 3/8″ QC Concentrate (in): 1/4″ QC Membranes: Membrane(s) Per Vessel: 1 Membrane Quantity: 1 Membrane Size: 2514 Vessels: Vessel Array: 1 Vessel Quantity: 1 Pumps: Pump Type: Aquatec 8800 System Electrical: Standard Voltage Amp Draw: 110V, 60Hz, 1PH, 4.0A Operating Limits: Maximum Feed Temperature (°F / °C): 85 / 29 Minimum Feed Temperature (°F / °C): 40 / 4 Maximum Ambient Temperature (°F / °C): 120 / 49 Minimum Ambient Temperature (°F / °C): 40 / 4 Maximum Feed Pressure (psi / bar): 85 / 6 Minimum Feed Pressure (psi / bar): 45 / 3 Maximum Operating Pressure (psi / bar): 110 / 7.5 Maximum Feed Silt Density Index (SDI): < 3 Maximum Turbidity (NTU): 1 Maximum Free Chlorine (ppm): 0 Maximum TDS (ppm): 1,000 Maximum Hardness (gpg): 1 Maximum pH (Continuous): 11 Minimum pH (Continuous): 2 Maximum pH (Cleaning 30 Minutes): 13 Minimum pH (Cleaning 30 Minutes): 1
